ViewSonic CDE8630-MTR 86" 4K Digital Display Conferencing System

The ViewSonic CDE8630-MTR is a complete Microsoft Teams Rooms conferencing system built around an 86 inch display that delivers 4K UHD resolution. Out of the box it arrives with three matched components—the large format screen, a Windows 11 IoT computing engine, and a 10.1 inch tabletop touch console—so meeting rooms move from unboxing to live calls in very little time.

The 3840 × 2160 panel produces 450 cd/m² brightness and a 1200:1 contrast ratio, while a 25 percent haze anti-glare coating keeps slides and video legible even under office lighting. An 8 ms response time helps motion stay smooth, making the display equally useful for video playback, interactive training, and data-rich presentations.

An Intel Core i3-1220P processor with 8 GB RAM and a 128 GB SSD runs Microsoft Teams Rooms on Windows 11 IoT, handling scheduling, screen sharing, and call management without an external PC. The wired touch console puts all meeting controls at a comfortable reach, and Gigabit Ethernet plus Bluetooth 5.3 let the system fit neatly into both hard-wired and wireless device environments. Wall-mounting hardware is included, which simplifies installation in boardrooms, classrooms, and training suites that need a reliable, professional video conferencing hub.

Highlights:

• 86 inch display that presents 3840 × 2160 resolution with TFT active matrix technology
• Intel Core i3-1220P computing engine paired with 8 GB RAM and 128 GB SSD
• Console with a 10.1 inch 1920 × 1200 LED backlit screen that supports multi-touch control
• Microsoft Teams Rooms certification ensures seamless meeting integration
• 450 cd/m² brightness, 1200:1 contrast ratio, and 25 percent haze anti-glare surface for clear viewing
• Gigabit Ethernet and Bluetooth 5.3 connectivity options for network and peripheral flexibility
• Windows 11 IoT Enterprise pre-installed for fast deployment
• Wall-mount hardware included for straightforward installation
